Socket: LGA1851
[Chipset] INTEL B860I
Form Factor: Mini ITX
Memory Specifications 1: 2 x DDR5 DIMM Slots.
Memory Specifications 2: Dual Channel DDR5 Memory Technology - 2 x DDR5 DIMM Slots - Supports DDR5 non-ECC, un-buffered memory up to 9333+(OC) * 1DPC 1R Up to 9333+ MHz (OC), 6400 MHz Natively. 1DPC 2R Up to 6800+ MHz (OC), 6400. MHz Natively. - Supports Clocked Unbuffered DIMM (CUDIMM) - Max. capacity of system memory: 128GB - Supports Intel Extreme Memory Profile (XMP) 3.0x * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/)
- 2 x DDR5 DIMM Slots
Phase: 10+1+1+1+1+1 Power Phase, 110A SPS for VCore+GT+SA
【GPU Function】Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. - Intel Xe LPG Graphics Architecture - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz - 1 x Intel Thunderbolt. TM 4, supports HD Resolution up to 8K 60Hz / 5K 120Hz* Supports two 4K displays or one 8K display * Only the CPU's embedded graphics can be displayed through Thunderbolt ports. If you want to display to a Thunderbolt monitor, please use CPU models with embedded graphics.
Graphics Output: 1 HDMI, 1 Thunderbolt 4 Type-C
[PCIE] 1 PCIe 5.0 x16
[PCIE X1] -
OC:
[SLI] -
Cross Fire:
Sound Function: Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio
[USB2.0] 3 USB 2.0 (1 Rear, 2 Front.
【USB3.2 Gen1 (USB3.0) 5Gb/s】6 USB 3.2 Gen1 (4 Rear, 2 Front)
USB 3.2 Gen2/Thunderbolt3 10Gb/s 1 USB 3.2 Gen2 Type-C (Front) 2 USB 3.2 Gen2 Type-A (Rear)
【USB3.2Gen2x2 Type-C 20Gb/s】
[Thunderbolt 4 (USB 4.0)] 1 Thunderbolt 4 Type-C (Rear)
【Thunderbolt 4 Header】
[SATA3] 3
M.2 Slot: 1 Hyper M.2 (PCIe Gen4 x4)
[M.2 Slot Heatsink] 1 Blazing M.2 (PCIe Gen5 x4)
【M.2 Wi-Fi】-
Wireless LAN: 802.11axe Wi-Fi 6E + Bluetooth
LAN: Realtek 2.5G LAN
LED: Confirming

Brand	ASRock
Manufacturer	ASRock
Series	B860
Package Dimensions	23.09 x 19.3 x 9.7 cm; 1.16 kg
Batteries	1 CR2032 batteries required.
Item model number	B860I LIGHTNING WIFI
Processor Socket	LGA 1851
RAM Size	128 GB
Memory Technology	DDR5
Computer Memory Type	DIMM
Memory Clock Speed	9333 MHz
Graphics Card Interface	Integrated, PCI Express
Wireless Type	802.11ax
Number of HDMI Ports	1
Number of Ethernet Ports	1
Are Batteries Included	No
Lithium Battery Energy Content	220 Milliampere Hour (mAh)
Lithium Battery Packaging	Batteries contained in equipment
Lithium Battery Weight	0.06 Grams
Nombre de cellules Lithium-Métal	1
Item Weight	1.16 Kilograms

ASRock Motherboard B860I Lightning WiFi Intel CPU Core Ultra (LGA1851) Compatible B860I Chipset DDR5 Mini ITX Motherboard
